Drive Shaft Balancing Machine.
Production Description
This is a Balancing Machine for Drive Shaft,we have many kinds of balancing machine for any Drive Shaft.
Range of Application
This balancing machine is equiped with hard bearing structure. Electromechanical transducer adopts piezoelectric sensor Large output,small size, stable performance .Mainly used in the production and repair of all kinds drive shaft factories.With the advantages of high measuring speed, high precision, easy to load and unload, Investment at low cost .it is an ideal device for shaft manufacturers and maintenance factories.
One Piece Drive Shaft Balancing Machines
| Technical data at a glance | PHC-100 | PHC-350 | PHC-1100 | PHC-3500 |
| Max Mass of Workpiece (kg) | 100 | 350 | 1100 | 3500 |
| Effective length of workpiece(mm) | 2000 | 2000 | 3000 | 3000 |
| Max Diameter of Workpiece(mm) | Φ130 | Φ130 | Φ400 | Φ400 |
| Shaft tube diameter of workpiece(mm) | Ø120 | Ø120 | Ø300 | Ø300 |
| Balancing speed(mm) | 16001) | 16001) | 410-7501) | 410-7501) |
| Motor Power(KW) | 1.52) | 2.22) | 32) | 5.52) |
| Universal joint torque(N.M) | 60 | 60 | 300 | 300 |
| Min Achievable Residual Unbalance Amount(e mar ) | Less than or equal to 2.5g | Less than or equal to 2.5g | Less than or equal to 2.5g | Less than or equal to 2.5g |
| Once reduced rate ( percent ) | Greater than or equal to 90 | Greater than or equal to 90 | Greater than or equal to 90 | Greater than or equal to 90 |
Two and Three Piece Drive Shaft Balancing machines
| Technical data at a glance | PHCT-100 | PHCT-350 | PHCF-100 | PHCF-350 |
| Max Mass of Workpiece (kg) | 100 | 350 | 100 | 350 |
| Effective length of workpiece(mm) | 4500 | 4500 | 4000 | 4000 |
| Max Diameter of Workpiece(mm) | Φ130 | Φ130 | Φ130 | Φ130 |
| Shaft tube diameter of workpiece(mm) | Ø120 | Ø120 | Ø120 | Ø120 |
| Balancing speed(mm) | 32001) | 32001) | 32001) | 32001) |
| Motor Power(KW) | 2.22) | 2.22) | 2.22) | 2.22) |
| Universal joint torque(N.M) | 60 | 60 | 60 | 60 |
| Min Achievable Residual Unbalance Amount(e mar ) | Less than or equal to 2.5g | Less than or equal to 2.5g | Less than or equal to 2.5g | Less than or equal to 2.5g |
| Length of bed (mm) | 6000 | 6000 | 7000 | 7000 |
| Once reduced rate ( percent ) | Greater than or equal to 90 | Greater than or equal to 90 | Greater than or equal to 90 | Greater than or equal to 90 |
1)Stepless speed regulation
2)Frequency conversion
